W6 184QAX: Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router

Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router
Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router

Compliant with Wi-Fi 6 technology, AirLive 11ax router W6 184QAX contributes great advantages including greater scalability, less Interference, advanced WPA3 higher security , high density & faster performance, responsive lower latency, wider coverage and more. It is 1.25 times faster wireless speed, 4 times greater network capacity and efficiency in traffic dense environment, comparing to 1200ac.

Besides, the AirLive W6 184QAX  is integrated with Qualcomm Quad-Core 64-bit 1.2Ghz CPU, 256MB DDR3 high speed RAM and 128MB Flash memory that ensure stable working up to 128 devices. For wired connectivity, there are 1 x Gigabit WAN port and 3 x Gigabit LAN ports equipped.

Advanced & Multiple functions
Advanced & Multiple functions
Rich and advanced helpful functions are supported by W6 184QAX, including Smart Easy MESH roaming, VPN remote working, and IPTV (Port 3) high priority port to enjoy watching movies freely.

Professional users can program and install additional functions to the devices based on its preload OpenWrt OS.
Smart Easy MESH
Smart Easy MESH

One SSID
Always Connected, Roaming Freely

Nowadays everything connects to internet, many families have several routers at home. When you walking from first floor to other floor, the WiFi may be disappeared due to the SSID changing. Not to mention if your house structure is built with many walls, the signal will be weak. AirLive W6 184QAX MESH router can help.

The router supports Smart Easy MESH Roaming that multiple SSIDs of W6 184QAX will be set in one SSID automatically by MESH system.  It lets you wipe out dead spots and fill in the gaps in your home coverage and enjoy Wi-Fi in every room located in each floor.

Follow Your Signal
Follow Your Signal
Range Boost + MESH
Provide continuous and stable signal


Different than traditional router which provides fixed wireless signal range, W6 184QAX features advanced Smart Easy MESH Roaming and Range Boost technology as well as four high-gain antennas. The router will detect and concentrate wireless signal strength towards connected wireless devices that greatly improves your network coverage.
Coloring & Mark
Coloring & Mark
OBSS Technology
Interference avoidance


W6 184QAX supports OBSS technology. The technology improves the spectral efficiency by providing a better signal-to-noise ratio (SNR) that prevents interference.

Thank to OBSS technology, the router and devices identify local traffic and tune out noise from other network. Therefore, whole wireless networking efficiency can be much enhanced.
Work from home
Work from home
VPN Server
Secure Connection for Remote Working

AirLive W6 184QAX brings much more for you working from your home. It supports VPN technology, a virtual private network safe and encrypted connective over a less secure network such as Internet.

Building your security tunnel between your home and office, you can work remotely.

An IPTV Router
An IPTV Router
Plug & Chill
Enjoying Internet TV Freely


One reason the W6 184QAX stands out is due to the astonishing download speeds. IPTV function able to define a priority range based on data types. Time-sensitive data such as video/audio data will have a higher priority than normal data, so you don’t need to worry about if there are other network users download a huge data who affecting your internet TV. This router will stream IPTV with easy.

Just Plug and Play, then you can enjoy movie via Internet TV at home at any times.
Parental Control
Parental Control
Time usage and URL

Worry that videos or data your children watch on Internet may be inappropriate for their age?

The “Parental Control” function, provided by AirLive W6 184QAX  can assist parents to limit internet usage by time and block unsuitable URL. So you can set your child’s internet connect time by daily basis.
WiFi 6 Open Router
WiFi 6 Open Router
Build the router you need

The OpenWrt SDK provides C and C++ alongside a variety of other supported scripting languages that allows the development of complex applications directly on the hardware.

The Developer Kit currently supports more Erlang, Java, Lua, NodeJS, Perl, PHP, Python and Ruby.
This software-based flexibility provides together with the high transmission power in the 2.4 and 5GHz range for a perfect router solution in professional environment.
ModelW6 184QAX : Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router

Device Interface

Main Chip: Qualcomm IPQ6000, Quad Core, 64-bit
Flash:128MB
RAM:DDR3 256MB
Ethernet (LAN): 3 x RJ45 10/100/1000mbps
WAN: 1x RJ-45 10/100/1000mbps
WiFi:
- 2 x 802.11ax/ac/n 2T2R(2.4Ghz)
- 2 x 802.11ax/ac 2T2R (5Ghz)
Button: WPS/Reset x 1, MESH x 1, Power x 1
Power Input: 1 x 12VDC 1 or 1.5A acceptable
Data Rate: 5.8Ghz 1200Mbps, 2.4Ghz 600Mbps
Antenna Connector:
- 2 x Wireless Antenna 5dBi (5Ghz)
- 2 x Wireless Antenna 5dBi (2.4Ghz)
WANWAN: PPPoE, DHCP, Static IP, Transparent Bridge
WiFiStandard: IEEE 802.11a/b/g/n/ax, 2x2, 20/40/80 MHz channels
Functions: Multi-SSID, SSID hidden ,SSID isolation
Security: WEP, WPA, WPA2, WPA3,WPA-PSK, 802.1x
Modulation : 1024-QAM modulation rates
Wi-fi Advanced: Wireless client isolation, STBC, WMM multimedia acceleration
Wireless Channel (CE Only)
- 2.4G: 1~13
- 5.8G: 36,40,44,48,52,56,60,64,100,108,112,116,120,124,128,132,136,140
Wireless TX Power (CE Only)
- 2.4G:20dbm Max
- 5.8G:TX 23dbm Max
Wireless Frequency Range (EG Only)
- 2.4G: 2.4-2.4835GHz
- 5.8G: 5.150~5.250Ghz
Wireless TX Power (EG Only)
20dbm Max
IPv6IPv6 RA/ Prefix apps

Firewall/Filtering

Firewall Level: high, Middle, low
Filter Rule: URL Filter/Mac Filter
URL filtering: White list/Black List.
DMZDMZ
IPTVVLAN support, IPv4, IPv6
LAN1/LAN2/LAN3

Port Forwarding Rule/Range

TCP/UDP
VPNPPTP L2TP VPN Server
L2TP/PPTP client
UPnPUPnP
DDNS3322.org
dyndns.org
no-ip.com
easydns.com
dnsexit.com
Dnsomatic.com
he.net
dnsdynamic.org

Parental Control

Mac Address Filtering
URL Filtering
MESHEasy Mesh
Controller
Agent
Status
SNMPV1/2c agent

Data Statistics

Lan
WAN
WIFI 2.4G
WIFI 5.8G

Multiple Language

English / Arabic

Environment

Operating temperature:0°C ~ +50°C
Storage Temperature:-10°C ~ +70°C
Humidity:10% ~ 90% (non-condensing)
Enclosure: Plastic

Ordering Information

ModelAirLive W6 184QAX
- W6 184QAX: Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router
 AirLive W6 184QAX-EG
- W6 184QAX: Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router
Standard Package
Package Size27.5(L) x 27(W) x 4(H) cm
Package WeightN.W: 0.5KGS
G.W: 0.6KGS
Package Content1 x Router, 1 x Power Adapter
Carton Package
Quantity20 PCS / 1 Carton
Dimensions56(L) x 46.5(W) x 30(H) cm
Weight13.6 KGS
QIG
NameDescriptionDownloadDate
W6-184QAX QIG
QIG of Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router
2021/05/05
User Guide
NameDescriptionDownloadDate
AirLive W6184QAX User Manual
Wi-Fi 6 AX 1800 Indoor Gigabit Router
2022/03/14
Spec Sheet
NameDescriptionDownloadDate
W6-184QAX Spec sheet
Spec sheet of Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router
2021/06/11
W6-184QAX-EG Spec sheet
Spec sheet of Wi-Fi 6 1800Mbps Easy MESH & VPN Dual Bands Gigabit Router
2021/06/11
CE
NameDescriptionDownloadDate
W6184QAX - CE
2021/05/11
DM
NameDescriptionDownloadDate
AirLive W6184QAX Wi-Fi 6 is Here Brochures
Brochures of W6184QAX Wi-Fi 6 is Here
2021/04/28
Firmware & Software
NameDescriptionDownloadDate
W6184QAX Firmware 05-11
Release 05-11-2021
2021/11/05
W6184QAX Firmware 10-07
Release 10-07-2021
2021/07/10
W6184QAX Firmware
Initial Release
2021/06/25
GPL Code
NameDescriptionDownloadDate
W6-184QAX - GPL Code
2021/05/31
